100L 316L Stainless Steel Chamber Grinding Horizontal Bead Mill Machine 55kW For Food, Chocolate
The main feactures of Bead Mill Machine:
1. Different materials for meeting different needs :
SUS 304 stainless steel,316Lstainless steel,zirconia ceramics,etc
2. Decrease the temperature:
self-owned double spiral cooling technology
3. Strengthen the fineness,better tasty is better
4. Enhance the efficiency:
higher 10-30% than traditional machines and processing technology
Main Technical Parameter
| NO. | Main parameter | SP100 | Note |
| 1 | Main motor power(kW) | 55 | 3phase,230V 50Hz |
| 2 | Effective Volume(L) | 100 | |
| 3 | Water presure Mpa | 0.3 | |
| 4 | Cooling water consumption (L/min) | 2.5 -3m3/h | The lower limit can be selected for the water consumption, in case that the cooling water temperature is lower than 10℃. |
| 5 | Overall dimension (mm) | 2040*1200*1840 | |
| 6 | Weight (kg) | 1800 | |
Configuration instructions
1. Outer Chamber: 304 stainless steel
2. Inner Chamber: 304stainless steel/ zirconia ceramincs/ 316L stainless steel
3. Dispersing shaft: 40Cr with hard chromium plating
4. Dispersing disk: 304 Stainless steel / 316L stainless steel
5. Mechanical seal: double mechanical seal
6. Feeding and discharging end covers on the chamber: 304 stainless steel /316L stainless steel
7. Turbine centrifugal separator and pigs: 304 stainless steel /zirconia ceramics
8. statistic discharge screen ring: 304 stainless steel screen ring with 304
9. Feeding pump: 1.5" ARO pneumatic diaphragm pump, Ingersoll Rand
Workplant disply
Packing and shipping:
Be covered with anti-abrasion film and then packed in wooden boxes, then seashipping by FCLor LCL.
Related products: Dispersing machine & the Zirconical beads, This 2 products are much important for the Bead mills, this materials is pre-dispersing well, It's better for grinding with bead mill after pre-dispesing well. Also the zirconia beads (grinding beads with different size for meeting different finally fineness.
The Exhibition show
we also positively particaipate in different industries meetings and exhibitions to show our allwin company to customers, to learn more information to make progress.
If need more detailed information, please don't hesitate contact us, Also Warmly welcome to visit us.
